DS-2PT5326IZ-DE

(5-50 mm)(4 mm) PanoVu Mini Series IR Network PTZ Camera

System Functions

  • 3-ch panoramic images in different directions and 1-ch close-up image
  • Three flexible cameras are adjustable along a circular track, slide range: 0° to 270°
  • Three flexible cameras can tilt rotate from 15° to 55° independently
  • 1-ch audio input and 1-ch audio output
  • 1-ch alarm input and 1-ch alarm output, support alarm linkage
  • PTZ linkage
  • Built-in memory card slot, support microSD/SDHC/SDXC, up to 256 GB
  • Open-ended API, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform
  • Support H.265 video compression
  • IP66

Panoramic Camera

  • Three 1/2.8" progressive scan CMOS
  • UP to 3-ch 1920 × 1080@30fps resolution
  • Min. illumination: Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001 Lux @(F1.6, AGC ON) 0 Lux with IR
  • Horizontal FOV: 80.7° × 3 Vertical FOV: 43.5°
  • Up to 30 m IR radius

PTZ Camera

  • 1/2.8" progressive scan CMOS
  • Up to 1920 × 1080@30fps resolution
  • Min. illumination: Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001 Lux @(F1.6, AGC ON) 0 Lux with IR
  • 10× optical zoom, 8× digital zoom
  • Up to 50 m IR distance
