DS-K1T604MF

Face Recognition Terminal

  • Wall mounting
  • 17.78cm(7-inch) LCD touch screen to display operation interface, etc.
  • Screen ratio: 16:9
  • Screen resolution: 1280p × 600p
  • 2 MP wide-angle dual-lens
  • WDR
  • QR code
  • Face recognition distance: 0.3 m to 1 m
  • Suggested person height for recognition: 1.4 m to 1.9 m
  • High performance processor with deep learning algorithm
  • Max. 10000 face pictures
  • Multiple authentication modes: authentication by comparing face picture, by swiping card and comparing face picture, by custom mode, etc.
  • Accurate and fast face recognition function. The face recognition duration is no more than 0.5s per person and the face recognition accuracy rate is more than 99%
  • Applies face picture data and card data to the device via TCP/IP or uploading them to the device via the USB flash drive
  • Stand-alone operation
  • Transmits and saves the comparing results and the captured face pictures to the client software or others
  • Device management, log search, and parameter settings via the device.
  • Imports the data (face pictures) from the USB flash drive to the device or exports the data (face pictures and events) from the device to the USB flash drive
  • Connects to one external card reader via RS-485 communication or Wiegand communication
  • Connects to external access controller via RS-485 communication or Wiegand communication
  • Connects to secure door control unit to avoid the door opening when the terminal is destroyed
  • Two-way audio
  • Voice prompts
  • Watchdog design for protecting the device and ensuring device running properly
